2025 Suzuki KingQuad 750 AXi Power Steering SE+ - S0269

MSRP $11,529

$11,529

OUR PRICE

Payments From

$0/mo

More Info

Get in Touch

    Description

    2025 Suzuki KingQuad 750AXi Power Steering SE+

    The KingQuad 750AXi Power Steering SE+ is not just an ATV, it's a KingQuad ATV.

    Suzuki, the inventor of the 4-wheel ATV, has created the world’s best sports-utility quad with bold styling plus more capability and reliability than ever before. The legacy of the iconic KingQuad remains fresh and exciting, and is ready for you to join its history. The KingQuad 750AXi Power Steering SE+ helps tackle challenging terrain with the capabilities that only a KingQuad possesses.

    Features May Include:

    • The 722cc, DOHC, single-cylinder, liquid-cooled, four-stroke engine delivers strong low- to mid-range torque and impressive peak horsepower. The four-valve cylinder head has large 36mm intake valves and straight ports for superb cylinder charging efficiency. A sportbike-derived chain-and-gear camshaft drive system helps create a compact engine.
    • The Quadmatic™ CVT-type automatic transmission provides versatility and convenience with a fender-mounted gate-type shifter for high/low range selection. Its advanced engine-braking system minimizes free-wheeling with the throttle off to help reduce speed when riding downhill.
    • Independent double A-arm front suspension (6.7 inches of wheel travel) and the fully independent, A-arm/I-beam rear suspension (7.7 inches of wheel travel) use four large diameter, gas-charged shock absorbers with five-way spring preload adjustment.
    • The multi-function instrument panel has excellent appearance and visibility and provides service reminders based on running time or mileage. The instrumentation includes LCD readouts for the speedometer, odometer, twin trip meter, hour meter, clock, fuel level, riding range, and drive mode. There are LED indicators for high, low, neutral, reverse, 2WD/4WD, and differential-locked 4WD and LED cautions for fuel injection and engine temperature.

    Dealer Notes

    Color Options

    Cast Carbon: +$0

    Pricing

    Warranty (Months): 24

    Engine

    Engine Type: Single-Cylinder

    Cylinders: 1

    Cooling: Liquid

    Bore: 104 mm; 4.1 in

    Stroke: 85 mm; 3.35 in

    Displacement: 722 cc; 44.1 ci

    Compression Ratio: 9.9:1

    Starter: Electric

    Fuel Type: Gas

    Emissions Standards: Meets California Emissions

    Carburetion Type: Fuel Injected

    Transmission

    Transmission Type: Continuously Variable (CVT)

    Reverse: Yes

    Drive Line

    Driveline Type: Selectable 4X2 / 4X4

    Technical Specifications

    Length: 84.6 in; 2150 mm

    Width: 47.8 in; 1215 mm

    Height: 50.6 in; 1285 mm

    Wheelbase: 50.6 in; 1285 mm

    Ground Clearance: 10.2 in; 260 mm

    Wet Weight: 721 lbs; 327 kg

    Towing Capacity: 1322 lbs; 599.7 kgs

    Fuel Capacity: 4.6 gal; 17.5 l

    Storage Capacity: 0.6 gal

    Exterior

    Frame: Steel

    Suspension

    Front Suspension Type: Independent Double A-Arm

    Front Travel: 6.7 in; 170.2 mm

    Rear Suspension Type: Independent Double A-Arm

    Rear Travel: 7.7 in; 195.6 mm

    Wheels & Tires

    Front Tire (Full Spec): Carlisle AT 25 X 8-12

    Rear Tire (Full Spec): Carlisle AT 25 X 10-12

    Brakes

    Front Brake Type: Dual Hydraulic Disc

    Rear Brake Type: Sealed Oil Bath Multi-Disc

    Seats

    Seat Height: 36.2 in; 920 mm

    Number Of Seats: 1

    Instrumentation

    Speedometer: Standard

    Trip Odometer: Standard

    Lights

    Type: Halogen


    Info

    Industry

    Powersports

    Make

    Suzuki

    Model

    KingQuad 750 AXi Power Steering SE+

    Trim

    Base

    Year

    2025

    Msrp

    11529

    Price

    11529.00

    Stock Number

    S0269

    Category

    ATV

    Subcategory

    Utility

    Condition

    New

    Location

    North Idaho Rec & Marine

    Vin

    5SADW11H6S7100269

    Color

    CAST CARBON


    Specifications

    Enginee

    722cc (44.1 cubic in.), 4-stroke, liquid-cooled, 4-valve, DOHC single cylinder

    Bore x Stroke

    104.0 mm x 85.0 mm (4.094 in. x 3.346 in.)

    Compression Ratio

    9.9:1

    Fuel System

    Suzuki electronic fuel injection

    Ignition/Starter

    Electronic ignition (transistorized)/Electric

    Lubrication System

    Wet sump

    Transmission

    Automatic variable ratio (V-belt), with high/low-range, and reverse

    Suspension (Front)

    Independent, double wishbone, coil spring, gas charged and oil damped with 5-way preload adjustable shock absorbers

    Suspension (Rear)

    Independent, double wishbone, coil spring, gas charged and oil damped with 5-way preload adjustable shock absorbers

    Front Brake

    Disc brakes, twin rotors

    Rear Brake

    Sealed oil-bathed multi-disc

    Front Tire

    AT25 x 8-12**, tubeless type x 2

    Rear Tire

    AT25 x 10-12**, tubeless type x 2

    Fuel Capacity

    17.5 L (4.6 US gal.)

    Fuel Type

    Gasoline

    Length

    2150 mm (84.6 in.)

    Width

    1215 mm (47.8 in.)

    Height

    1285 mm (50.6 in.)

    Wheelbase

    1285 mm (50.6 in.)

    Ground Clearance

    260 mm (10.2 in.)

    Seat Height

    920 mm (36.2 in.)

    Warranty

    24-month limited warranty
