2026 CFMOTO CFORCE 500 CF500AZ-10S Magma Red- C0222

Color Options

Magma Red: +$0

Pearl White: +$0

True Timber Camo: +$350

Pricing

Warranty (Months): 12

Engine

Engine Type: Single-Cylinder

Cylinders: 1

Horsepower: 34 bhp; 25.4 kW

Cooling: Liquid

Displacement: 500 cc; 30.5 ci

Starter: Electric

Fuel Type: Gas

Carburetion Type: Fuel Injected

Transmission

Transmission Type: Continuously Variable (CVT)

Reverse: Yes

Drive Line

Driveline Type: Selectable 4X2 / 4X4

Technical Specifications

Length: 80 in; 2032 mm

Width: 44 in; 1117.6 mm

Height: 45 in; 1143 mm

Wheelbase: 50 in; 1270 mm

Ground Clearance: 10.3 in; 261.6 mm

Dry Weight: 713 lbs; 323.4 kg

Towing Capacity: 1350 lbs; 612.4 kgs

Fuel Capacity: 4.5 gal; 17 l

Exterior

Frame: Steel

Suspension

Front Suspension Type: Independent Double A-Arm

Front Travel: 7.5 in; 190.5 mm

Rear Suspension Type: Independent Double A-Arm

Rear Travel: 8.9 in; 226.1 mm

Wheels & Tires

Front Tire (Full Spec): 25 x 8 R12

Rear Tire (Full Spec): 25 x 10 R12

Brakes

Front Brake Type: Hydraulic Disc

Rear Brake Type: Hydraulic Disc

Seats

Seat Height: 20 in; 508 mm

Number Of Seats: 1

Instrumentation

Speedometer: Standard

Tachometer: Standard

Trip Odometer: Standard

Storage

Capacity: 75 lbs; 34 kgs

Capacity: 132 lbs; 59.9 kgs

Lights

Type: LED

Glass

Windshield: Optional
